SEMA Racking Inspection — Code of Practice, Tolerances & Methodology
A SEMA racking inspection is a formal competent-person assessment of pallet racking carried out to the Storage Equipment Manufacturers Association Code of Practice by a SARI accredited inspector. Damage is measured against published tolerances and classified red, amber or green, with a written report issued for HSG76 and PUWER compliance.
A SEMA racking inspection is the formal UK methodology for assessing pallet racking safety — carried out by a SARI accredited inspector working to the SEMA Code of Practice and HSE guidance HSG76. This page explains what specifically distinguishes a SEMA inspection from a generic visual check, the exact measurable tolerances used, and how Rackstor UK Ltd applies them in real inspections.
What Makes a SEMA Racking Inspection Different
SEMA — the Storage Equipment Manufacturers Association — publishes the UK Code of Practice for the Use of Static Pallet Racking. This document is the reason "SEMA racking inspection" is a specific, defined thing rather than a generic term. The Code sets out the inspection methodology, the components that must be assessed, the red / amber / green risk classification system, and — critically — the precise measurable tolerances that separate safe from unsafe.
A generic racking check is a visual walk-round based on the inspector's judgement. A SEMA racking inspection is different: damage is measured against published numerical tolerances. If a leg is bent, the question isn't "does that look bad?" — it's "does the deflection over a 1 metre gauge exceed 3mm?". That objectivity is what SEMA specifically adds, and it's what HSE guidance HSG76 defers to when it refers to competent-person inspections under PUWER 1998.
SEMA's Precise Damage Tolerances
These are the measurable limits a SEMA-aligned inspector works to. Damage below the tolerance is monitored; damage at or above it triggers a red / amber classification and a defined remedial action.
| Component / measurement | SEMA tolerance |
|---|---|
| Upright frontal (cross-aisle) deflection | Max 3mm over a 1m gauge |
| Upright lateral (down-aisle) deflection | Max 5mm over a 1m gauge |
| Bracing member deflection | Max 10mm |
| Beam deflection under load | Max Span / 200 |
| Beam residual deformation (unloaded) | Max Span / 1000 |
A SEMA racking inspection measures against these exact figures using a straight edge and gauge — not visual estimation. Reports quote the measured deflection against the tolerance, so remedial decisions are auditable.
Real SEMA Racking Inspection Case Studies & Audit Scores
Four real inspections carried out by Rackstor UK Ltd, showing what a SEMA-aligned methodology finds in practice — from serious impact damage to a clean bill of health.
- Envirowales Ltd, Ebbw ValeChronic forklift impact damage across adjustable pallet racking and longspan shelving — full remedial action plan produced.
- Gardner Denver UK Ltd, BradfordDexion Speedlock MKIII racking scored 52.2/100 (fair) — historical impact damage and missing beam locks identified for planned repair.
- Bio Zone Scientific UK Ltd, CardiffAR Sistemas and BigDug/Whalen systems — zero Red and zero Amber risks, no replacement components required.
- Absolute Motion Control Ltd, RedhillMaxrac and Link 51 systems scored 6.2/100 (excellent) — installation described as "exemplary" with only minor recommendations.
View the full set of case studies →
SEMA Racking Inspection FAQ
What does "SEMA" stand for?
SEMA stands for the Storage Equipment Manufacturers Association — the UK trade body that publishes the Code of Practice for the Use of Static Pallet Racking, which defines the formal methodology and measurable tolerances used in UK racking inspections.
Is a SEMA racking inspection a legal requirement?
The Health and Safety at Work Act 1974 and PUWER 1998 require racking to be inspected by a competent person at suitable intervals. The law does not name SEMA specifically, but the SEMA Code of Practice is the recognised UK methodology HSE guidance HSG76 defers to — so in practice, a SEMA-aligned inspection is how UK duty holders demonstrate compliance.
What's the difference between a SEMA inspection and a general safety inspection?
A general safety inspection is usually a visual walk-round with subjective judgement. A SEMA racking inspection follows the Code of Practice: damage is measured against precise numerical tolerances (e.g. 3mm frontal deflection over a 1m gauge), classified into red/amber/green risk categories, and reported against those figures — not against an inspector's opinion.
How do I verify an inspection was genuinely carried out to SEMA standards?
Ask for the inspector's SARI (SEMA-Aligned Racking Inspector) registration number and check it on the SEMA website's SARI directory. A genuine SEMA-aligned report will reference the SEMA Code of Practice, quote measured deflections against the published tolerances, and use SEMA's red/amber/green classification. Our lead inspector is Mr G. Thelwell, SARI No. 0100.
